Product Details
Coalescer serves as critical components in industrial compressed air and gas systems. The filtration media in coalescing systems undergoes application-specific engineering tailored for our customers needs.
Our product features high efficiency for oil/ low entrainment and carry-over, low pressure drop, especially in oil saturated phase.
 |  |
Air/oil coalescer grades for wrapped separators and/or pleated separators, compressed air, oil mixture collector
Product Code | FB2301 | FB3201 | FB3101 | FB2111 | FB1111 | ||
Reference | Lydall 9866 | HV 1145 | HV 848/2 | HV 1476 | HV 1477 | ||
Oil resistance | - | - | - | + | + | ||
Water resistance | + | + | + | + | + | ||
Basis Weight | g/㎡ | TAPPI T410 | 98 | 80 | 85 | 85 | 85 |
Thickness | Mm | TAPPI T411 | 0.43 | 0.42 | 0.52 | 0.53 | 0.55 |
Efficiency (DOP 0.3 μm) | % | TSI 8130 | 95 | 99.97 | 95 | 90 | 70 |
Pressure drop (DOP 0.3μm) | Pa | 136 | 330 | 170 | 92 | 51 | |
PMI mean flow pore size | Μm | ASTM F316 | 4.6 | 2.3 | 4.2 | 5.9 | 8.4 |
Tensile strength – MD | kN/m | TAPPI T494 | 1.61 | 1.80 | 1.95 | 1.87 | 1.60 |
Tensile strength – CD | kN/m | TAPPI T494 | 0.97 | 1.32 | 1.57 | 1.16 | 1.03 |
Gurley stiffness – MD | Mg | TAPPI T494 | 1780 | 2600 | 3400 | 2760 | 2800 |
Cost
Area used
Basis weight
Scrap rate
Processing speed
Emissions control
